New Holland TR96, TR97, TR98 Combine Service Repair Manual

Print No. –

Manual Type: Service Manual
Total Pages: 1866

Models Covered:

TR96, TR97, TR98 Combine
New Holland

Manual Contents:

SECTION 0 – GENERAL AND SAFETY INFORMATION
SECTION 1 – ELECTRICAL SYSTEM
SECTION 2- HYDRAULIC SYSTEM
SECTION 3- MONITOR SYSTEM
SECTION 4- SEPARATOR CLUTCH
SECTION 5- ENGINE PTO
SECTION 6- FEEDER
SECTION 7- ROTOR DRIVE
SECTION 8- ROTORS
SECTION 9- ROTOR GEARBOXES
SECTION 10 – CONCAVES
SECTION 11 – SEPARATOR GRATES
SECTION 12 – DISCHARGE BEATER AND GRATE
SECTION 13 – CLEANING FAN
SECTION 14 – CLEANING SHOE
SECTION 15 – CLEAN GRAIN AND FILLING SYSTEM
SECTION 16 – TAILINGS SYSTEM
SECTION 17 – UNLOADING SYSTEM
SECTION 18 – MAIN SHAFT
SECTION 19 – HYDROSTATIC SYSTEM
SECTION 20 – TRANSMISSION
SECTION 21 – POWERED REAR AXLE
SECTION 22 – FINAL DRIVES
SECTION 23 – BRAKES
SECTION 24 – CYLINDERS
